HME Wireless IQ - Message Repeater Operation

15
Message Repeater Operation
(Refer to Figure 2 on page 2)
To record RED MESSAGE
Be certain the RED MESSAGE switch is in the ON position.
Press and release the RECORD MODE button on the base station once.
⎯ The red MESSAGE RECORD light on the base station will come on.
Press and hold button B on the COMMUNICATOR
®
and talk into the
headset microphone to record a message (up to 15 seconds).
⎯ The MESSAGE RECORD light on the base station will begin blinking.
Release button B. ⎯ The record function will stop and the
MESSAGE RECORD light will go off.
To record GREEN MESSAGE
Be certain the GREEN MESSAGE switch is in the ON position.
Press and release the RECORD MODE button on the base station twice.
⎯ The green MESSAGE RECORD light on the base station will come on.
Press and hold button B on the Communicator and talk into the
headset microphone to record a message (up to 15 seconds). ⎯
The MESSAGE RECORD light on the base station will begin blinking.
Release button B. ⎯ The record function will stop and the
MESSAGE RECORD light will go off.
Locate the RED MESSAGE and GREEN MESSAGE switches, and
the RED MESSAGE CONTROL and GREEN MESSAGE CONTROL
DIP switches inside the front door of the base station for the
following settings.
Red Message Switch
In the ON position, the RED MESSAGE switch enables the “Red
Message” to be played. A playing message can be cancelled by
pressing Communicator button A.
Red Message Control
Switch 1 enables inbound audio from speaker post to be heard
while message is playing.
Switch 2 enables message to be played to all Communicators.
Switch 3 enables message to be played on the outside speaker.
Switch 4 enables message to be played on the ceiling speaker.
Switch 5 causes message to be triggered by an external alert signal.
Switch 6 (only used in tandem systems, on secondary base station)
in OFF position, “Please pull forward” message plays once.
in ON position, “Please pull forward” repeats every 4 seconds.
Switches 7 and 8 not used
Green Message Switch
In the ON position the GREEN MESSAGE switch enables the
“Green Message” to be played. A playing message can be
cancelled by pressing Communicator button A.
Green Message Control
Switch 1 enables inbound audio from speaker post to be heard
while message is playing.
Switch 2 enables message to be played to all Communicators.
Switch 3 enables message to be played on the outside speaker.
Switch 4 enables message to be played on the ceiling speaker.
Switch 5 causes message to be triggered by an external alert signal.
Switch 6 causes a 3 second delay before message is played.
Switch 7 not used
Switch 8 selects a “dual-beep” vehicle tone for the lane 2 base
station in a dual lane configuration.
NOTE:
If both RED MESSAGE
and GREEN MESSAGE
switches are in the ON
p
osition, and are selected
f
or the same output, Red
and Green Messages will
be played alternately.
After a new message has
been recorded or after the
base station has lost and
regained power, any
message to the outside
speaker will always be
heard in the
Communicator headset
the first three times it
p
lays, whether Switch 1 is
in the ON or OFF position.
CAUTION:
In Tandem base
stations, the
red message
“Please pull
f
orward” i
s
p
r
e
-recorded.
Recording a new
red message will
replace the pre-
recorded message.
NOTE:
The RED MESSAGE
switch does not need to
be in the ON position to
enable the “Red Message”
to be played when the
TANDEM switch is on.
