Wireless IQ Base Station
All functions of the drive-thru audio system are channeled through
the base station. It is the electronic heart of the Wireless IQ.
External base station features are shown in Figure 2, and
described on page 3. Internal controls and connectors are shown
in Figure 11 on page 20.
External Features
Figure 2. Base station with front door open
A
C
B
