– 6 –
OPERATION
Moving agitator in bowl. Keep hands, clothing and utensils out while in
operation. Do not use without interlocked guard.
The Legacy mixer is equipped with SmartTimer™ controls and a manual bowl lift. Other operating parts
(Fig. 2) and their functions are described throughout the Operation section.
The bowl guard wire cage must be in closed position or the mixer will not operate.
The bowl must stay in mix position on bowl support and the bowl support must be raised (mix position) or
the mixer will not operate.
Controls
Attachment
Hub
Wire Cage
Drip Cup
Agitator
Splash Guard
Apron
Bowl
Support
Bowl Lock
Lever
Fig. 2
