34
11.1.2 BOWL LOCKING MECHANISM.
Bowl Locking Mechanism should be lubricated after cleaning. Clean only if sticking or
hanging up.
11.1.3 PLANETARY SEAL.
Occasionally, the planetary seal (Fig. 10, page 33) may become dry and begin to
squeak. To correct this, work a little lubrication (mineral oil) under the lip of the
seal.
11.1.4 TRANSMISSION OIL.
Transmission oil should be checked once yearly or more depending on machine use. To
check the oil level, remove the top cover, which is secured by two screws. Remove the
Transmission Fill Plug (Fig. 11) and check the oil level. If the oil level is below the line
on the oil dipstick, add a small amount of the recommended transmission oil until it
returns to the proper level. Do not overfill the transmission, as leakage may result.
Contact your local Hobart Service Office for the recommended transmission oil.
Figure 11.
