Hobby optima - Changing Taillight Bulbs

Maintenance and Care
12-3
12.3 Changing the taillight bulbs
• Removethedefectlampfrom
thelightingsupportandpull
outthecablebypressingthe
two clamps
k
together.
•Unscrewthelightbulbfrom
thelampbyturingthepin
l
in the direction of the arrow.
•Unscrewthelightbulbfrom
thesocket
m
andexchange
it for a new one.
• Carryoutthisprocedurein
reversetoputeverythingback
in place.
• Unscrewthetwoscrews
j
in the defect lamp.
1
3
4
2
Ifseverallightbulbshavetobereplaced,takecareto
ensurethatthelampsarenotswitchedbyaccidentand
thateverythinggoesbackinitsoriginalplace.
