Hobby optima - Hanging Table

Interior Structure
06-7
Hanging table
When lowered, the hanging table can be used as a base frame
for the bed.
To lower
• Fully retract the lower, pivotable table top
j
until it locks
into place by itself.
• Press the lock
k
down
• Raise the front end of the table top
l
by approx. 30°.
• Pull down the lower section of the table foot
m
and
remove it.
• Pull the table top out of the upper wall bracket
n
.
• Hook the table top into the lower wall bracket
o
. The lock
must move up to lock into place.
• Place the shortened supporting leg
p
at the front edge of
the table top on the oor.
To swivel out
• Pull the locking pin
q
.
• Swivel the lower table top
j
to the desired position.
1
5
3
4
8
6
7
2
The A65 GM and A70 GM models do not have a pivotable
table top.
In models with alcove beds, the hanging table cannot be
lowered, because there is no need to convert it into a bed
as you have the alcove bed.
