3.4 Levelling supports *
The levelling supports are located in the rear area by the
frame extension.
Swinging out the levelling supports
• Placethecrankonthehexagonhead
j
.
• Turnthecranktomovethesupporttoaverticalposition.
• Ifnecessary,securethefoot
k
to prevent it from sinking
intothegroundandplaceitonarmbase.
• Ifthelevellingsupportisinaverticalposition,thesupport
foot will extend telescopically.
• Usethecranktolevelthelevellingsupportsuntilthevehi-
cle stands level.
Retracting levelling supports
• Usecranktoreleaselevellingsupports.
• Continuetocranksmoothlyuntilthelevellingsupportisonce
again in its initial horizontal position.
- Do not use the levelling supports as a car jack. Their sole
purpose is to stabilise the motor home when it is parked.
- Always load the levelling supports evenly (max. 500 kg per
support).
- Always retract the levelling supports and secure them
before driving.
-Cleanthelevellingsupportsregularlyandgreasethemslightly.
2
1
2
The telescopically adjustable foot may only be extended
as far as the yellow marking!
