Exterior Structure
05-9
Petrol ller neck
The black petrol cap is covered by a ap located on the left
side of the vehicle behind the driver's door in the lower sec-
tion of the B-pillar.
Opening
• Open the ap by placing a nger in the notch
j
and
pulling out/forwards.
Closing
• Push the ap until it locks.
Please refer to the separate operating instructions from
FIAT for information on how to operate the petrol cap.
3
2
1
Fresh water ller neck
Opening
• Hold the ap by the latch
j
and pull it up.
• Use key to unlock
k
.
• Give the blue cap
l
a strong turn counter-clockwise and
remove it.
Closing
• Put the blue cap
l
back on and turn it clockwise to shut it.
• Use key to lock
k
.
• Hold the ap by the latch
j
and close it until it clicks into
place.
Never ll diesel into the fresh water tank.
