Hobby optima - Toilet Flap

Exterior Structure
05-6
Garage ap/ Stowage ap (model-specic)
Opening
• Unlatch both locks with the key. The handles will be slightly
projected.
• Turn the handle to the left.
• Swing the ap up.
Closing
• Swing the ap shut.
• Turn the handle to the right until the ap is pulled into the seal.
• Latch both locks with the key and push the handles in until
they click into place.
The maximum load for the external storage locker is 150 kg.
Toilet ap
Opening
• Use key to unlock ap
j
.
• Press both buttons (
j
and
k
) and open ap.
Closing
• Press ap until it locks into place.
• Use key to lock ap
j
.
2
1
