7. Electrical Installations
109
All12Velectricaldevicesaresupplieddirectlybytheancillary
battery.In230Vmainsoperation,theyarechargedautomatically
by the battery charger.
Allofthelampsinthevanuse12VLEDlights.Onlylargeelec-
tricaldevicessuchastheCombiEheating*, air-conditioning
system,etc.,use230V.
7.4 Electrical system
Assignment of fuses
Assignment of fuses
The fuses for the individual internal electric circuits are loca-
tedintheinputmodule.
Insomemodels,theremaybeslightdeviationsinthis
assignment.
Onlyreplacedefectfusesifyouknowwhatcausedthe
fusetoblowandhavexedthis.
