6. Interior Structure58
6.6 Washroom
A removable insert
j
has been placed in the shower tray to
protect it and make it easier to walk across.
1
The insert must be removed from the shower tray before
taking a shower.
6.7 Windows
Knockout windows with locking hooks
1
2
Depending on how the window has been constructed, it has
one or more latches with locking knobs
j
. To open these
window latches, press the locking knobs
j
.
Opening
• Turn the latch
k
by 90°.
• Press the window latch outwards until you hear it click.The
window will automatically remain in this position. The width
of the opening is adjustable in several stages.
Window latch
Shower tray
