6. Interior Structure 51
Lowering/removing the table
• Fully retract the lower, pivotable table top
k
until it locks
into place by itself.
• Press the lock
l
down
• Raise the front end of the table top
m
by approx. 30°.
• Pull down the lower section of the table foot
n
and
remove it.
• Pull the table top out of the upper wall bracket
o
.
• Hook the table into the lower wall bracket or stow it securely
inside the vehicle. When the table has been lowered, push
the lock
l
back up again to lock the table into the mount.
• Place the shortened supporting leg
p
at the front edge of
the table top on the oor.
6.5 Seating arrangements and sleeping areas
Emergency bed in the seating arrangement*
The seating arrangement can be converted to an emergency
bed.
If the van has been tted with a Milano seating bench*, the
seating arrangement cannot be converted.
7
Lowered hanging table
