7. Electrical Installations100
Supply via mains connection
Thevanisconnectedtotheexternal230VmainsbyaCEE
feederplug
j
located in the side wall.
To connect the CEE feeder plug
• Switchotheautomaticcircuitbreaker
j
(p. 101)bypres-
singtherockerswitch
k
down (p.101).
• Flipupthecoverapoftheexternalsocket
k
(see also p. 41).
•Completelyunwindtheconnectorcable.
•OpenthecapoftheCEEconnectorplug
l
bypullingitupina
90°angle.
•Inserttheplug
m
untilitlocksintoplace.
• Switchtheautomaticcircuitbreaker
j
(p. 101)backon.
Connected 230V feeder plug
4
1
2
3
7.3 Electric power supply
Inallofthevehicles,thecentralelectricalsystemisinstalled
underneath the passenger seat.
Electricityforthevancanbeobtainedfromthefollowing
connections:
-230Vmainsconnection50Hz
-viathegeneratorwhenthemotorisrunning
- via the ancillary battery
Everythingthatuses12V,suchaslighting,watersupply,etc.,
is available.
External socket
