10
hobie.com
Once the crossbars are completely inserted, slide the tramp halves in
the front crossbar into the hull/tramp tracks on each hull. Use of soap
or spray silicone to lube the track can help if it is difficult to slide in.
Three lace lines are provided. The longer lace line (17’) will be tied to
the forward end of the center lace grommets with a bowline knot. Lace
the line through all of the center grommets to the rear of the
trampoline as shown (by number) in the illustration. Lace the rear of
the tramp starting from the outboard ends toward the center.
Tension all lace lines and tie off with half hitches at the rear/center of
the trampoline.
3
10’ line
10’ line
17’ line
slide into groove on aft bar
slide into tramp track
slide into groove
on front bar
tighten aft end first
“follow number for lacing sequence”
1
1
2
2
3
3
4
4
5
5
6
6
Assembly Required
