6
hobie.com
Anatomy
1. (1) Mast float
2. (2) Rudder assemblies
3. (2) Mast pieces
4. (1) Rear crossbar
5. (1) Tiller crossbar, Tramp Rod
6. (2) Hulls with hardware bag
7. (1) Tramp and Main crossbar
8. (1) Main sail
(1) Box of small parts
Large Components
1
2
3
4
5
6
7 8

Table of Contents

Other manuals for Hobie Wave

Preview: Parts Guide
Parts Guide2 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Hobie Wave and is the answer not in the manual?

Hobie Wave Specifications

General IconGeneral
Length13 ft / 3.96 m
Beam7 ft / 2.13 m
Hull MaterialPolyethylene
TypeCatamaran
Capacity4 adults
Mast Length20 ft / 6.10 m
