Assembly Required
The Club Wave incorporates a Hobie standard three-piece trampoline
assembly with lace lines in the center of the rear trampoline.
Insert the left and right main sections into the forward crossbar
(grommets toward the center and rear of the boat) and the rear lacing
strip into the rear crossbar. Lift the front crossbar and insert the left
end into the left hull. Pick up the rear crossbar and insert the left end
into the left hull. The crossbars have stops built into the underside that
will limit the depth that the crossbar can be inserted.
Reach up and hold the right end of the front crossbar, and pull it down.
This will rotate the left hull to the upright position. Straddle the right
hull and rotate it to the upright position by grabbing the crossbar
insert hole on the outboard side and pulling it horizontal to the ground.
Insert the front crossbar partially. Align and insert the rear crossbar
partially. Working front and rear, wiggle hull onto crossbars until fully
inserted.
1
2
Club Wave Crossbar and Trampoline Assembly

Hobie Wave Specifications

General

Length	13 ft / 3.96 m
Beam	7 ft / 2.13 m
Hull Material	Polyethylene
Type	Catamaran
Capacity	4 adults
Mast Length	20 ft / 6.10 m
