Hoffmann Megaplan Megaspin - UNBALANCE CORRECTION; Iron rims

25
Ver. 04-2015
Use and Maintenance Manual
ENGLISH
Displays the information screen
Selects unbalance display in g/oz
Traceability management
Enables/disables wheel in correction position
Unbalance split (not selectable for correction
with clip-on weights)
Displays the second set of buttons
Lift reset with wheel stopped / STOP during spin
WEIGHT APPLICATION POSITION
Correction type Inside Outside
Clip-on weight at 12 o’clock Clip-on weight at 12 o’clock
Clip-on weight at 12 o’clock Adhesive weight at 12 o’clock
Adhesive weight at the point indicated
by the internal laser
Clip-on weight at 12 o’clock
Adhesive weight at the point indicated
by the internal laser
Adhesive weight at 12 o’clock
Adhesive weight at the point indicated by the internal laser
Use of the wheel balancing machine
6.7 UNBALANCE CORRECTION
After an unbalance measurement spin, the weight shadow indicates the correct application point.
6.7.1 Iron rims
