Wheel lifting
4. WHEEL LIFTING (OPTION)
▪ Position the wheel on the carriage resting it against the ZERO WEIGHT carriage lever. Check that the
pneumatic spindle is enabled for mounting (open); if not, push the pneumatic locking pedal.
▪ Push the Zero Weight pedal.
cAuTIoN:
NeveR push The ZeRo WeIGhT pedAl If TheRe Is ANyoNe sTANdING IN The RANGe of AcTIoN of The lIfT.
cAuTIoN:
befoRe pushING The pedAl To lIfT A Wheel, AlWAys checK ThAT The spINdle Is opeN
(If NoT, The lIfT mIGhT NoT AsceNd oR AsceNd INcoRRecTly).
As soon as the wheel lifts off the ground, it is ready for mounting on the wheel balancing machine at zero
weight.
▪ Position the central hole of the wheel at the height of the spindle and slide the wheel onto the spindle
with the aid of the Zero Weight carriage lever.
Zero Weight carriage lever
Pneumatic locking pedal Zero Weight pedal
