Hofmann ATC 900 - Page 4

CTC-CEN Service Manual 07-13 Rev.E
4
7.22 Manometer: Check and replacement Pag. 66
7.23 Spiral pipes: Check and replacement Pag. 68
CHAPTER 8 MECHNICAL SECTION Pag. 70
8.0 Mechanical section Pag. 70
8.1 Opening arm bushings # 1-10065A check and replacement Pag. 70
8.1.1 Opening arm bushings # 1-10065A check and adjustment Pag. 74
8.2 Automatic tool # EAA0356G25A: check, replacement and adjustment Pag. 75
8.3 Horizontal arm rollers: check and adjustment Pag. 80
8.4 Gear box # EAA0347G76A: check and replacement Pag. 80
8.5 Bead breaker discs # EAM0065G63A: Check and replacement Pag. 81
8.6 Bead breaker discs # EAM0065G63A: Check and replacement Pag. 82
8.7 Bead breaker discs bearing # 1-06963A: Check and replacement Pag. 83
8.8 Bead breaker discs inclination adjustment. Pag. 84
8.9 Bead breaker discs clearance: Check and adjustment Pag. 85
8.10 Bead breaker carriage: Check and adjustment Pag. 87
8.11
Lead screw nut # EAM0076G10A: Check and adjustment Pag. 87
CHAPTER 9 TROUBLE SHOOTING Pag. 89
CHAPTER 10 SERVICE BULLETINS Pag. 92
