TMPC0 Register
• HT66F20
Bit 7 6 5 4 3 2 1 0
Name — —
T1CP1 T1CP0 — — — T0CP0
R/W — — R/W R/W — — — R/W
POR — — 0
1 — — — 1
Bit7~6 Unimplemented,readas“0”
Bit5 T1CP1:TP1_1pinControl
0:Disable
1:Enable
Bit4 T1CP0:TP1_0pinControl
0:Disable
1:Enable
Bit3~1 Unimplemented,readas“0”
Bit0 T0CP0:TP0_0pinControl
0:Disable
1:Enable
• HT66F30
Bit 7 6 5 4 3 2 1 0
Name
T1ACP0 — T1BCP1 T1BCP0 — — T0CP1 T0CP0
R/W R/W — R/W R/W — — R/W R/W
POR
1 — 0 1 — — 0 1
Bit7 T1ACP0:TP1ApinControl
0:Disable
1:Enable
Bit6 Unimplemented,readas“0”
Bit5 T1BCP1:TP1B_1pinControl
0:Disable
1:Enable
Bit4 T1BCP0:TP1B_0pinControl
0:Disable
1:Enable
Bit3~2 Unimplemented,readas“0”
Bit1 T0CP1:TP0_1pinControl
0:Disable
1:Enable
Bit0 T0CP0:TP0_0pinControl
0:Disable
1:Enable
