• HT66F40/HT66F50/HT66F60
Bit 7 6 5 4 3 2 1 0
Name
T1ACP0 T1BCP2 T1BCP1 T1BCP0 — — T0CP1 T0CP0
R/W R/W R/W R/W R/W — — R/W R/W
POR
1 0 0 1 — — 0 1
Bit7 T1ACP0:TP1ApinControl
0:Disable
1:Enable
Bit6 T1BCP2:TP1B_2pinControl
0:Disable
1:Enable
Bit5 T1BCP1:TP1B_1pinControl
0:Disable
1:Enable
Bit4 T1BCP0:TP1B_0pinControl
0:Disable
1:Enable
Bit3~2 Unimplemented,readas“0”
Bit1 T0CP1:TP0_1pinControl
0:Disable
1:Enable
Bit0 T0CP0:TP0_0pinControl
0:Disable
1:Enable
