Holtek HT66F30 User Manual

Rev. 2.50 110 June 22, 2017 Rev. 2.50 111 June 22, 2017
HT66F20/HT66F30/HT66F40/HT66F50/HT66F60
HT66FU30/HT66FU40/HT66FU50/HT66FU60
A/D Flash MCU with EEPROM
HT66F20/HT66F30/HT66F40/HT66F50/HT66F60
HT66FU30/HT66FU40/HT66FU50/HT66FU60
A/D Flash MCU with EEPROM
TMPC1 Register
• HT66F40
Bit 7 6 5 4 3 2 1 0
Name — — — — — —
T2CP1 T2CP0
R/W — — — — — — R/W R/W
POR — — — — — — 0
1
Bit7~2 Unimplemented,readas“0”
Bit1 T2CP1:TP2_1pinControl
0:Disable
1:Enable
Bit0 T2CP0:TP2_0pinControl
0:Disable
1:Enable
• HT66F50/HT66F60
Bit 7 6 5 4 3 2 1 0
Name — —
T3CP1 T3CP0 — — T2CP1 T2CP0
R/W — — R/W R/W — — R/W R/W
POR — — 0
1 — — 0 1
Bit7~6 Unimplemented,readas“0”
Bit5 T3CP1:TP3_1pinControl
0:Disable
1:Enable
Bit4 T3CP0:TP3_0pinControl
0:Disable
1:Enable
Bit3~2 Unimplemented,readas“0”
Bit1 T2CP1:TP2_1pinControl
0:Disable
1:Enable
Bit0 T2CP0:TP2_0pinControl
0:Disable
1:Enable
