Rev. 2.50 16 June 22, 2017 Rev. 2.50 17 June 22, 2017
HT66F20/HT66F30/HT66F40/HT66F50/HT66F60
HT66FU30/HT66FU40/HT66FU50/HT66FU60
A/D Flash MCU with EEPROM
HT66F20/HT66F30/HT66F40/HT66F50/HT66F60
HT66FU30/HT66FU40/HT66FU50/HT66FU60
A/D Flash MCU with EEPROM
HXT:Highfrequencycrystaloscillator
LXT:Lowfrequencycrystaloscillator
*:VDDisthedevicepowersupplywhileAVDDistheADCpowersupply.TheAVDDpinisbonded
togetherinternallywithVDD.
**:VSSisthedevicegroundpinwhileAVSSistheADCgroundpin.TheAVSSpinisbondedtogether
internallywithVSS.
AsthePinDescriptionSummarytableappliestothepackagetypewiththemostpins,notalloftheabove
listedpinsmaybepresentonpackagetypeswithsmallernumbersofpins.
HT66F30
Pin Name Function OP I/T O/T Pin-Shared Mapping
PA0~PA7 Port A
PAWU
PAPU
ST CMOS
PB0~PB5 Port B PBPU ST CMOS
PC0~PC7 Port C PCPU ST CMOS
AN0~AN7 ADC input ACERL AN PA0~PA7
VREF ADC reference input ADCR1 AN PB5
C0-, C1- Comparator 0, 1 input
CP0C
CP1C
AN PA3, PC3
C0+, C1+ Comparator 0, 1 input AN PA2, PC2
C0X, C1X Comparator 0, 1 output CMOS PA0, PA5
TCK0, TCK1 TM0, TM1 input ST PA2, PA4
TP0_0, TP0_1 TM0 I/O TMPC0 ST CMOS PA0, PC5
TP1A TM1 I/O TMPC0 ST CMOS PA1
TP1B_0, TP1B_1 TM1 I/O TMPC0 ST CMOS PC0, PC1
INT0, INT1 Ext. Interrupt 0, 1 ST PA3, PA4
PINT Peripheral Interrupt PRM0 ST PC3 or PC4
PCK
Peripheral Clock output PRM0 CMOS PC2 or PC5
SDI
SPI Data input PRM0 ST PA6 or PC0
SDO
SPI Data output PRM0 CMOS PA5 or PC1
SCS SPI Slave Select PRM0 ST CMOS PB5 or PC6
SCK SPI Serial Clock PRM0 ST CMOS
PA7 or PC7
SCL I
2
C Clock PRM0 ST NMOS PA7 or PC7
SDA I
2
C Data PRM0 ST NMOS PA6 or PC0
SCOM0~SCOM3 SCOM0~SCOM3 SCOMC SCOM
PC0, PC1, PC6, PC7
OSC1 HXT/ERC pin CO HXT PB1
OSC2 HXT pin CO HXT PB2
XT1 LXT pin CO LXT PB3
XT2 LXT pin CO LXT PB4
RES Reset input CO ST PB0
VDD
Power supply* PWR
AVDD
ADC power supply* PWR
VSS
Ground** PWR
AVSS
ADC ground** PWR
Note:I/T:Inputtype; O/T:Outputtype
OP:Optionalbycongurationoption(CO)orregisteroption
PWR:Power; CO:Congurationoption; ST:SchmittTriggerinput
CMOS:CMOSoutput; NMOS:NMOSoutput
SCOM:SoftwarecontrolledLCDCOM; AN:Analogsignal
HXT:Highfrequencycrystaloscillator
