ERSATZTEI LE / SPARE PARTS
HOLZMANN Maschinen Austria  www.holzmann-maschinen.at
Seit e 4 8
Metalldrehmaschine / metal turning lathe ED 750 FDQ
P1 0 V4
1 ………………………P10V401 ….………………………..………………………SHAFT
2 ………………………P10V402 …………………………………………………WASHER
3 ………………………..10V401 ……………..……………….... INT RETAINING 22mm
4 ……………………GB10V402 ………………...….……………...…BEARING 1000900
5 ………………………P10V403 ……………………………....………………. GEAR 30T
6 ……………………GB10V403 …………...……………….………FLAT WASHER 6mm
7 ……………………GB10V404 ……………..………….……………CAP SCREW M6x8
8 ………………………P10V404 ………………………..……………………SHIFT ARM
9 ………………………P10V405 ……………………………………………...…BUSHING
10 ………………………P10V406 ………………….………………….………GEAR 40T
11 ……………………GB10V405 …………………….…………SPECIAL WASHER 9mm
12 ……………………GB10V406 …………………………….……………OIL PORT 6mm
13 ………………………P10V407 ….…………………………………………...……SHAFT
14 ………………………P10V408 ………….………………………………LOCATING PIN
15 ………………………P10V409 ……………………….……………………….... SPRING
16 ………………………P10V410 ………………….………………...………...…BUSHING
17 ………………………P10V411 ………………..……….………………. SPACING RING
18 ………………………P10V412 ……………………………..……….………GEAR 40T
19 ………………………P10V413 ……………………….…………………………PULLEY
20 ………………………..10V407 ……………………………………CAP SCREW M8x8
21 ………………………P104V14 …………………….………………………...…WASHER
22 ………………………P104V15 ………………………………….………SPANNER NUT
23 ……………………GB10V408 ………………………………………BEARING 2007107
24 ………………………P10V416 ………………………………...…………………COVER
25 ………………………P10V417 ….………………………………………………GASKET
26 ……………………GB10V409 …………………….………………………KEY A4x50
27 ………………………P10V418 …………………….…………..…………….... SPINDLE
28 ………………………P10V419 ………………….…..…………...…LOCATING BLOCK
29 ………………………..B10410 ………………….………………………..…. PIN 3x20
30 ………………………GB10411 …………………………..………CAP SCREW M6x16
31 ………………………GB10412 ……………………….…………………HEX NUT M6
32 ………………………P10V420 ……………………..…………….….…………HANDLE
33 ……………………GB10V413 ………………………...……………...…CAP NUT M6
34 ……………………GB10V414 ……………………….….………CAP SCREW M6x12
35 ………………………P10V421 …………………………………………………WASHER
36 ………………………P10V422 ……………………..……………LOCATING BUSHING
37 ………………………P10V423 ….…………………………………….……………RING
38 ………………………P10V415 ………………………..……………SET SCREW M4X8
