ERSATZTEI LE / SPARE PARTS
HOLZMANN Maschinen Austria www.holzmann-maschinen.at
Seit e 6 1
Metalldrehmaschine / metal turning lathe ED 750 FDQ
P1 0 1 2
1----------------GB101201------------------------------------------------------------HEX NUT M4
2----------------GB101202-----------------------------------------------------CAP SCREW M4x12
3----------------P101201-------------------------------------------------------------------------GIB
4----------------GB101203---------------------------------------------------CAP SCREW M4x20
5----------------P101202---------------------------------------------------------------------SCREW
6----------------GB101204----------------------------------------------------------------PIN 3x10
7----------------GB101205--------------------------------------------------------OIL PORT 10mm
8----------------GB101206------------------------------------------------------------HEX NUT M6
9----------------GB101207----------------------------------------------------FLAT WASHER 6mm
10---------------P101203---------------------------------------------------------------------COVER
11---------------GB101208----------------------------------------------------HEX SCREW M6x25
12---------------P101204--------------------------------------------------------GRADUATED DIAL
13---------------GB101209----------------------------------------------------------------PIN 4x16
14---------------GB101210----------------------------------------------------CAP SCREW M6x16
15---------------GB101211----------------------------------------------------CAP SCREW M5x16
16---------------P101205--------------------------------------------------------GRADUATED DIAL
17---------------P101206--------------------------------------------------------------------SPRING
18---------------P101207-------------------------------------------------------------HAND WHEEL
19---------------GB101212---------------------------------------------------FLAT WASHER 8mm
20---------------GB101213------------------------------------------------------------HEX NUT M8
21---------------P101208-------------------------------------------------------------------HANDLE
22---------------P101209-----------------------------------------------------LEAD SCREW MOUNT
23---------------GB101214---------------------------------------------------------OIL PORT 6mm
24---------------GB101215-------------------------------------------------------------KEY A3x10
25---------------P101210--------------------------------------------------------------LEAD SCREW
26---------------P101211-------------------------------------------------------------SWIVEL BASE
27---------------P101212--------------------------------------------------------COMPOUND SLIDE
28---------------P101213----------------------------------------------------------------TOOL REST
29---------------GB101216---------------------------------------------------SET SCREW M8x30
30---------------P101214-------------------------------------------------------------------WASHER
31---------------P101215-----------------------------------------------------------------LOCK NUT
32---------------P101216-------------------------------------------------------------------HANDLE
33---------------P101217-------------------------------------------------------------------HANDLE
34---------------P101218------------------------------------------------------------------------KEY
35---------------P101219-------------------------------------------------------------------------PIN
36---------------GB101217-------------------------------------------------- -SPRING 0.5x3.5x17
