101
OPERATION
(RI, R2, R3 type)
Some indicator and/or buzzer will be activated at the same time due to the occurrence of a malfunction.
*: Occasionally may blink due to the occurrence of a malfunction.
System
Symptom
INDICATOR BUZZER
Oil pressure
(Green)
Overheat
(Red)
ACG
(Red)
PGM-FI
(Red)
CORRESPONDING
SYSTEM
At starting ON (2 sec) ON (2 sec) ON ON (2 sec)
With the engine key
turned on: ON (2 times)
During operation ON OFF OFF OFF OFF
Low oil pressure OFF OFF OFF OFF ON (continuously)
Overheat ON ON OFF OFF ON (continuously)
ACG warning ON OFF ON OFF
alternating ON and OFF
(at long intervals)
PGM-FI warning ON* OFF* OFF ON
alternating ON and OFF
(at long intervals)
Water contamination ON OFF OFF OFF
alternating ON and OFF
(at short intervals)
