102
OPERATION
(Display Assy type)
Some indicator and/or buzzer will be activated at the same time due to the occurrence of a malfunction.
*: Refer to 105 page about power reduction.
System
Symptom
INDICATOR BUZZER
WA RN I N G
LEVEL
Power
Reduction*
Oil pressure
(Red)
Overheat
(Red)
ACG
(Red)
PGM-FI
(Red)
CORRESPONDING
SYSTEM
During operation OFF OFF OFF OFF OFF OFF OFF
Low oil pressure ON OFF OFF OFF ON (continuously) ON
Overheat OFF ON OFF OFF ON (continuously) ON
ACG warning OFF OFF ON OFF
alternating ON and OFF
(at long intervals)
OFF
PGM-FI warning OFF OFF OFF ON
alternating ON and OFF
(at long intervals)
OFF
Water contamination OFF OFF OFF OFF
alternating ON and OFF
(at short intervals)
OFF
Warning level 1
Warning level 2
Warning level 2
