11
CONTROLS Choke Knob
Emergency Stop Switch Clip
and Emergency Stop Switch
CONTROLS AND FEATURES
EMERGENCY STOP SWITCH
EMERGENCY STOP
SWITCH CLIP
EMERGENCY STOP
SWITCH CLIP
CHOKE KNOB
OONN
OOFFFF
EMERGENCY STOP
SWITCH LANYARD
EMERGENCY STOP SWITCH LANYARD
The choke knob opens and closes the
choke valve in the carburetor.
The ON position enriches the fuel
mixture for starting a cold engine.
The OFF position provides the
correct fuel mixture for operation
after starting, and for restarting a
warm engine.
The emergency stop switch clip must
be inserted in the emergency stop
switch in order for the engine to start
and run. The emergency stop switch
lanyard must be attached securely to
the operator or to the operator’s PFD
(Personal Flotation Device).
When used as described, the
emergencystopswitchand
emergency stop switch lanyard
system stops the engine if the
operator falls away from the controls.
A spare emergency stop switch clip is
provided in the tool bag (p. ).38
