26
EMERGENCY STARTING
OPERATION
RECOIL STARTER
5 mm NUTS
ENGINE COVER
FLYWHEEL
PULLEY
EMERGENCY STARTER ROPE
If the recoil starter is not working
properly, you can start the engine
manually using the emergency starter
rope supplied with the tool kit.
Remove the engine cover. Set the controls the same as for
normal starting (see pages
). Use the choke control if
needed.
Remove the three 5 mm nuts with
an 8 mm wrench and remove the
recoil starter.
Set the knotted end of the
emergency starter rope in the notch
in the flywheel pulley. Wind the
rope clockwise around the
flywheel pulley, as shown.
4.
3.1.
2.
25
23
09/04/17 16:10:57 31ZW6601_027
