13
Fuel Valve Lever Engine Cover Retaining StrapStarter Grip
CONTROLS AND FEATURES
OFF
ON
FUEL VALVE LEVER
ENGINE COVER
STARTER GRIP
RETAINING
STRAP
Direction to pull
Use the retaining strap to hold the
engine cover closed. Do not remove
the engine cover while the engine is
running.
The fuel valve opens and closes the
passage between the fuel tank and the
carburetor.
The fuel valve lever must be in the
ON position for the engine to run.
When the engine is not in use, leave
the fuel valve lever in the OFF
position to prevent carburetor
flooding and to reduce the possibility
of fuel leakage.
Pulling the starter grip operates the
recoil starter to crank the engine for
starting.
