16
AnodeOTHER FEATURES
Centrifugal Clutch (SCHA/
LCHA type)
Oil Level Inspection Window
CONTROLS AND FEATURES
OIL LEVEL INSPECTION WINDOW
UUPPPPEERR LLIIMMIITT
LLOOWWEERR LLIIMMIITT
Short shaft type Long shaft type
ANODE
Use the oil level inspection window
to check the engine oil level with the
engine stopped and the outboard
motor in the upright position.
The anode is made of a sacrificial
material that helps to protect the
outboard motor from corrosion.
The centrifugal clutch automatically
engages and transmits power when
engine speed is increased above
approximately 2,700 rpm. At idle
speed, the clutch is disengaged.
09/04/17 16:09:37 31ZW6601_017
