44
Lubrication Points
SERVICING YOUR OUTBOARD MOTOR
SWIVEL CASE
STEERING HANDLE
THROTTLE ARM
CHOKE ARM
TILT LEVER
CLAMP SCREW
THROTTLE ARM
STEERING FRICTION BOLT
TRANSOM ANGLE
ADJUSTING BOLT
THRUST RECEIVER
To prevent corrosion, apply anticorrosion oil to pivot
surf aces where grease cannot penetrate.
Apply Honda Marine waterproof grease to the parts
shown below:
Apply Honda Marine Corrosion Inhibitor (or equivalent) to all areas under the engine cover and any exposed metal
surfaces.
10 operating hours or one month after the date of
purchase or initial use, then every 50 operating hours or 6
months.
Lubrication interval:
09/04/17 16:13:33 31ZW6601_045
