Honda BF8D - Valve wire installation order

134
STORAGE
Valve wire installation order
BROWN/WHITE
BLACK/GREEN
Without the choke knob:
Reconnect the starting
enrichment thermal valve
wires securely.
Reassemble the removed parts.
Return the starting enrichment
system to the way it was before
starting the procedure.
Install the engine cover.
Install the emergency stop
switch clip to the emergency
stop switch (see pages and
).
(1)
(2)
(5)
5.
28
24
