Drive Chain
a
Adjusting the Drive Chain Slack
5. Check rear axle alignment by making
sure the scales on the drive chain
adjusters align with the index marks on
both sides of the swingarm.
Both scales should correspond. If the axle
is misaligned, turn the right or left
adjusting bolt until the scales are aligned
and recheck chain slack.
6. Tighten the rear axle nut.
Torque: 88 N·m (9.0 kgf·m, 65 lbf·ft).
7. Tighten the adjusting bolts lightly.
8. Recheck drive chain slack.
If a torque wrench was not used for
installation, see your dealer as soon as
possible to verify proper assembly.
Improper assembly may lead to loss of
braking capacity.
