Clean the oil strainer screen.Drain the engine oil (page ).
Refer to the Safety Precautions on page .
Remove the oil strainer screen cap ( ).
The spring ( ) and oil strainer screen
( ) will come out when the oil strainer
screen cap is removed.
Check that the oil strainer screen, sealing
rubber and O-ring ( ) are in good
condition.
1.
2.
3.
4.
5.1
4
(1)(4)(2)(3)
2
387
100
(1) Oil strainer screen cap
(2) Spring
(3) Oil strainer screen
(4) O-ring
ENGINE OIL STRAINER SCREEN
101
