Honda PCX - Rear Brake

−−
Place the scooter on its center stand.
Adjustment:
Adjust the freeplay of the brake lever with
the front wheel pointed straight ahead.
Measure the distance the rear brake
lever ( ) moves before the brake starts
to take hold.
Freeplay at the tip of the brake lever should
be:
2.
1.
(1)
1
(1) Rear brake lever
Rear Brake
30
10 20 mm (0.4 0.8 in)
