CBS Brake Fluid Level:
With the scooter in an upright position,
check the fluid level. It should be between
theUPPER()andLOWER()level
marks. If the level is at or below the
LOWER level mark, check the brake pads
forwear(page ).
Worn pads should be replaced. If the pads
are not worn, have your brake system
inspected for leaks.
The recommended brake fluid is Honda
DOT 3 or DOT 4 brake fluid from a sealed
container, or an equivalent.
Other Checks:
Make sure there are no fluid leaks. Check
for deterioration or cracks in the hoses and
fittings.
(1)
(2)
12
109
(1) UPPER level mark
(2) LOWER level mark
29
