Honda PCX - Fuel Gauge

The fuel gauge liquid crystal display ( )
shows the approximate available fuel in a
graduated display. When all segments up to
F ( ) are on, the fuel tank is full.
The fuel tank capacity is:
When there is only one segment ( ) left,
fuel will be low and you should refuel as
soon as possible.
The amount of fuel left in the tank with the
vehicle set upright is approximately:
This segment flashes when the fuel
decreases further.
(2)(1)
(3)
1
2
3
(1) Fuel gauge
(2) Segment F
(3) Segment E
Fuel Gauge
26
6.1
(1.61 US gal , 1.34 Imp gal)
1.5
(0.40 US gal , 0.33 Imp gal)
