The fuel tank is located behind the fuel lid.
Fuel tank capacity is:
Open the fuel lid ( ) (page ). Remove
thefuelfillcap()byturningit
counterclockwise.
After refueling, be sure to tighten the fuel
fill cap firmly by turning it clockwise.
Make sure that the arrow marks ( ) on the
fuel fill cap and fuel tank is aligned.
Close the fuel lid.
Do not overfill the tank. There should be
no fuel in the level plate ( ).
(2)
3
2
(1)
(4)
4
(3)
461
(1) Fuel lid
(2) Fuel fill cap
(3) Level plate
(4) Arrow marks
FUEL
Fuel Tank
35
6.1 (1.61 US gal , 1.34 Imp gal)
Petrol is highly flammable and
explosive. You can be burned or
seriously injured when handling fuel.
Stop the engine and keep heat,
sparks, and flame away.
Refuel only outdoors.
Wipe up spills immediately.
