Honda PCX - Fuel Lid and Seat Opener; Switch; Fuel Lid

Close the fuel lid until it locks. Make sure
the fuel lid is secure before riding.
Close the Fuel Lid:
Open the fuel lid ( ).
Insert the ignition key ( ) and turn it to
the position of ‘‘SEAT FUEL’’ ( ).
Open the Fuel Lid:
Push the ‘‘FUEL’’ ( ) side of the fuel lid
and seat opener switch.
If the ignition switch is ON or OFF position,
fuel lid and seat opener switch ( ) will not
operate.
1.
2.
3.
(5)1
2
(3) (2)
(1)
(4)
4
3
5
(3) ‘‘SEAT FUEL’’
(4) ‘‘FUEL’’
(5) Fuel lid
(1) Fuel lid and
seat opener switch
(2) Ignition key
Fuel Lid
FUEL LID AND SEAT OPENER
SWITCH
