GENERAL INFORMATION
1-11
BATTERY/CHARGING SYSTEM SPECIFICATIONS
IGNITION SYSTEM SPECIFICATIONS
ELECTRIC STARTER SPECIFICATION
Unit: mm (in)
LIGHTS/METERS/SWITCHES SPECIFICATIONS
ITEM SPECIFICATIONS
Battery Capacity 12 V – 11 (10) Ah
Current leakage 1.5 mA max.
Voltage
(20°C/68°F)
Fully charged Above 12.8 V
Needs charging Below 12.3 V
Charging
current
Normal 1.1 A/5 – 10 h
Quick 5.5 A/1.0 h
Alternator capacity 0.368 kW/5,000 min
-1
(rpm)
ITEM SPECIFICATIONS
Spark plug LMAR8A-9 (NGK)
Spark plug gap 0.8 – 0.9 mm (0.03 – 0.04 in)
Ignition coil primary peak voltage 100 V minimum
Crankshaft position (CKP) sensor peak voltage 0.7 V minimum
Ignition timing ("F" mark) 10° BTDC at idle
ITEM STANDARD SERVICE LIMIT
Starter motor brush length 10.0 – 10.5 (0.39 – 0.41) 6.5 (0.26)
ITEM SPECIFICATIONS
Bulb Headlight (high/low beam) 12 V - 60/55 W
Brake/taillight 12 V - 21/5 W
License light 12 V - 5 W
Turn signal light 12 V - 21 W x 4
Position light 12 V - 5 W x 2
Instrument light LED
High beam indicator 12 V - 1.12 W
Turn signal indicator 12 V - 1.4 W x 2
PGM-FI malfunction indicator LED
Engine oil pressure indicator 12 V - 1.4 W
Engine oil change indicator LED
Fuse Main fuse 30 A
Sub-fuse STD type 15 A x 1, 10 A x 5
ABS type 30 A x 2, 15 A x 1, 10 A x 6
