FUEL SYSTEM (PGM-FI)
6-44
FUEL LINE INSPECTION
FUEL PRESSURE RELIEVING/QUICK
CONNECT FITTING REMOVAL
• Before disconnecting fuel hose, relieve pressure
from the system as following procedures.
1. Turn the ignition switch "OFF".
Remove the luggage box (page 3-5).
Disconnect the fuel pump 5P connector.
2. Turn the ignition switch "ON".
3. Start the engine, and let it idle until the engine
stalls.
4. Turn the ignition switch "OFF".
5. Check the fuel quick connect fitting for dirt, and
clean if necessary.
Place a shop towel over the quick connect fitting.
6. Pull the rubber off the fuel feed pipe.
FUEL PUMP 5P CONNECTOR
QUICK CONNECT FITTING
SHOP TOWEL
RUBBER
FUEL FEED PIPE

Honda SH300 2008 Specifications

General

Displacement	279 cc
Bore x Stroke	72 mm x 68.5 mm
Compression Ratio	10.5:1
Fuel System	PGM-FI electronic fuel injection
Ignition	Digital transistorized with electronic advance
Front Suspension	Telescopic fork
Front Tire	110/70-16
Rear Tire	130/70-16
Engine Type	Liquid-cooled, 4-stroke, single-cylinder
Max Torque	26.5Nm / 6, 000rpm
Transmission	V-Matic
Rear Suspension	Dual shocks
Front Brake	Single 256 mm disc
Rear Brake	240mm hydraulic disc
