11 - 6 3800g/3800gHD/3800gPDF User’s Guide
Keyboard Modifiers Windows Mode Control +
ASCII
KBDCAS2 2-6
*Control + ASCII Off KBDCAS0 2-6
DOS Mode Control +
ASCII Mode On
KBDCAS1 2-6
*Turbo Mode Off KBDTMD0 2-6
Turbo Mode On KBDTMD1 2-6
*Numeric Keypad Off KBDNPS0 2-7
Numeric Keypad On KBDNPS1 2-7
*Auto Direct Conn. Off KBDADC0 2-7
Auto Direct Conn. On KBDADC1 2-7
Serial Port Connection RS-232 PAP232 1-7
Baud Rate 300 BPS 232BAD0 2-8
600 BPS 232BAD1 2-8
1200 BPS 232BAD2 2-8
2400 BPS 232BAD3 2-8
4800 BPS 232BAD4 2-8
9600 BPS 232BAD5 2-8
19200 BPS 232BAD6 2-8
38400 BPS 232BAD7 2-8
*57600 BPS 232BAD8 2-8
115200 BPS 232BAD9 2-8
Selection
Setting
* Indicates default
Serial
Command
# Indicates a
numeric entry
Page

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honeywell 3800g and is the answer not in the manual?

Honeywell 3800g Specifications

General IconGeneral
Scan speed270 sec/page
Wavelength630 nm
Decoding standardsCodabar Code 3 Interleaved 2 Matrix 2 Code 11, 93, 128 UPC, EAN/JAN GS1 GTIN ISBT 128
Dimensions (WxDxH)79 x 112 x 150 mm
Standard interfacesRS-232
Input voltage5 V
Power consumption235 mA
CertificationIEC60950-1, IEC60825-1 Class 1, FCC Part 15 Class B, UL, cUL, ICES-003 Class B, CE 2004/108/EC EMC, EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3. 2006/95/EC, GS, NOM-NYCE, MIC Class A, BSMI, C-Tick
Product colorBeige
Storage temperature (T-T)-40 - 60 °C
Operating temperature (T-T)0 - 50 °C
Operating relative humidity (H-H)0 - 95 %
Weight and Dimensions IconWeight and Dimensions
Weight158.8 g
