Honeywell 3800g User Manual

3800g/3800gHD/3800gPDF User’s Guide 3 - 9
• Discard
This exits without saving any Output Sequence changes.
Output Sequence Editor
Require Output Sequence
When an output sequence is Required , all output data must conform to an
edited sequence or the imager will not transmit the output data to the host
device. When it’s
On/Not Required , the imager will attempt to get the output
data to conform to an edited sequence, but if it cannot, the imager transmits all
output data to the host device as is.
When the output sequence is
Off , the bar code data is output to the host as the
imager decodes it.
Note: This selection is unavailable when the Multiple Symbols Selection is
turned on.
Enter Sequence
Default Sequence
Required
On/Not Required
* Off

Honeywell 3800g Specifications

General

Scan speed	270 sec/page
Wavelength	630 nm
Decoding standards	Codabar Code 3 Interleaved 2 Matrix 2 Code 11, 93, 128 UPC, EAN/JAN GS1 GTIN ISBT 128
Dimensions (WxDxH)	79 x 112 x 150 mm
Standard interfaces	RS-232
Input voltage	5 V
Power consumption	235 mA
Certification	IEC60950-1, IEC60825-1 Class 1, FCC Part 15 Class B, UL, cUL, ICES-003 Class B, CE 2004/108/EC EMC, EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3. 2006/95/EC, GS, NOM-NYCE, MIC Class A, BSMI, C-Tick
Product color	Beige
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Weight	158.8 g
