Honeywell 4600g User Manual

6 - 5
Wand Emulation Polarity
The Polarity can be sent as standard with black bars high, or reversed with
white bars high. Default = Black High.
Wand Emulation Idle
The idle describes the state of the imager when no data is being transmitted.
When in Wand Emulation mode, you must set the imager’s idle state to match
the idle state for the device to which the imager is connected.
Default = Idle
High
.
Data Block Size
This transmits the data in smaller blocks to prevent buffer overflow. Default =
40.
* Black High
White High
* Idle High
Idle Low
20
80
* 40
60

Honeywell 4600g Specifications

General

Wavelength	617 nm
Tilt angle range	27 - 42 °
Decoding standards	1D, 2D
Optical sensor resolution	752 pixels
Dimensions (WxDxH)	81 x 135 x 157 mm
Standard interfaces	USB, RS-232, Keyboard wedge, RS-485
Input voltage	4 - 14 V
Power consumption	382 mA
Certification	FCC Part 15, ICES-003, EN55022 Class A, ROHS, CE, UL
Product color	Gray
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Weight	184 g
