7847i-E Installation and Setup Guide
5-2
DHCP
OK/BAD
DHCP (Dynamic Host Configuration Protocol) indicates
server is performing satisfactorily.
Press the [space] key to go to the Physical Link display.
[F]
Testing Gateway
Run Network Diagnostic Test
Performs a set of network diagnostics that tests the
integrity of the links between the unit and the various
connection points (Redirs) to the receiver. Refer to
Section 6: Network Diagnostics.
System Status Displays
[S]
ECP 67 Tm Flt
xx 5 OK
Displays the zone and system fault status.
Press the [space] key to go to the next field.
Press the [backspace] key to go to the previous field.
1234 67 Tm Flt
5555 xx 5 OK
Displays the zone and system fault status.
Press the [space] key to go to the next field.
Press the [backspace] key to go to the previous field.
12345678 Tm Flt
5555555x 5 OK
Displays the zone and system fault status.
Press the [space] key to go to the next field.
Press the [backspace] key to go to the previous field.
1234567 Tm Flt
5555555 5 OK
The status of the unit can be viewed on the 7720P. The
status display includes:
• Zone input status (1234567) - the numbers 1-
7 represent the 7 mappings of the zone
input, and follow Honeywell's ADEMCO
high-speed format codes:
1 = New Event
5 = Normal
X = Not Enabled
• Tm – Tamper status follows high-speed format
codes above.
• Flt – Represents radio faults:
OK = Normal ; No fault
I – No network connectivity over IP and
fault time has expired
i – No network connectivity over IP and
fault time has NOT yet expired.
NOTE: The 7720P will not operate if the power line
voltage is removed.
[T]
Test Msg Sent
Test Alarm
Sends a test alarm to the Primary CS IP and the
Secondary if it is enabled.
