Accenta/Optima Engineer’s Manual
31
2 = LED Keypad:
The LED keypad is limited to show the last eight set periods with the eighth being the oldest. Zone, and
indicators will be lit to show zone in alarm . Flashing LED indicates the first zone in alarm. indicates the
status of the panel at the time of the alarm.
O = Omit Allow and Double Knock
1 = Double Knock
Double knock programming is used when zones are likely to create false activations. Double knock requires
two activations within 10 minutes of the same zone or a zone left open for 10 seconds.
NOTE: It is not advisable to apply Double Knock to magnetic door contacts. Double Knock cannot be
applied to Fire Zones. By default, no zones are in Double Knock mode and all zones are enabled as
Omit Allow.
LCD Keypad:
Programming a Zone as Double Knock
The scrolls through zones.
Press to toggle double knock status on or off.
Press [9] to turn all double knock zones on.
Press [0] to turn all double knock zones off.
• Press to enter into Event Log menu. LED’s 1 and 2 are on.
• Press [2] for LED keypad. The first zone to activate is indicated
by a flashing LED.
• Press [1 to 8] for the desired event or to go through events
in sequence.
• Press twice to leave the menu.
While in Engineer program mode press or press until
0>Omit allow & Double Knock is displayed then press .
• Press [1] to select Double Knock. The first zone is
displayed with status NO or YES.
• Press the [zone number] or to toggle the status
on or off.
• Press the or [zone number] to go to the other zones
and follow the same procedure as above.
• Press twice to leave the menu.
Event Log (contd)
12
3
4
5
6
7
8
12
3
4
5
6
7
8
1. Double Knock
2. Omit Allow
[1]
Omit Allow &
Double Knock
1: <Zone Name>
Double Knock:NO
1: <Zone Name>
Double Knock:YES
[zone number] or
