Rear View
1 Handle 6 Alarm Buzzer
2 Sensor Compartment 7
Gas Inlet (Pumped
Version)
3
Serial I/O Connector Port (Not intended to be used in explosive
atmospheres)
8 Alarm LED
4 I/O Connector Switch Port 9 Antenna
5
4-20mA In Connector Port
In addition to turning the instrument on and off, the multi-function button can be used to
control different parameters and make selections within the instrument’s menus. Also,
pressing the button activates display backlighting when it is off: Press the button once
when the backlighting is off to turn it on.
BW RigRat 30 User Manual
