Honeywell BW RigRat User Manual

Alarm Signal Summary
Normal Operation Mode
Type
Red
LED
Yellow
LED
Green
LED
Buzzer LCD Display Reading Notes
Over Range
5
beeps/s
600ms/s "+OL"
Blink
red
High
3
beeps/s
400ms/s
High alarm
icon and
reading
Blink
red
Low
2
beeps/s
200ms/s
Low alarm
icon and
reading
Blink
red
STEL
1
beep/s
200ms/s
STEL alarm
icon and
reading
Blink
red
TWA
1
beep/s
200ms/s
TWA alarm
icon and
reading
Blink
red
Unit Failure 3 beeps/s 200ms/s
Instrument fatal
error
Fail 2 beeps/s 200ms/s "FAIL"
Blink
red
Sensor generic
fail
Negative 1 beeps/s 200ms/s "-OL"
Blink
red
PID Lamp 1 beeps/s 200ms/s "LAMP"
Blink
red
PID lamp fail
Remote
Alarm
1 beeps/s 200ms/s
Units in alarm
in network
detail screen
Remote device
alarm in closed
loop network
External
Alarm
1 beeps/s 200ms/s
External
signal state in
"Input/output
state" screen
4~20mA input,
digital input
Pump 1 beeps/s 200ms/s
Blink pump
icon
Battery
critical
1 beeps/s 200ms/s
Battery
critical icon
Battery voltage
less than 3 to
3.5V for 4s, unit
will power off in
15 minutes. The
voltage
threshold is
