Honeywell CK75 - Keypad Overlay

TITLE
Model
DOCUMENT NO.
PAGE
CK75 Repair Manual
CK75
L3-GLBL-RPR-4254
(Rev A)
Page 11 of 42
Removal
1. Unclip the handstrap where it attaches near the bottom of the unit.
2. Remove the screw that attaches the other end of the handstrap to the back of the unit.
Installation
Installation is reverse order of removal. Tighten screw to 5.0 +/- 0.2 in-lb of torque when installing.
OPERATION:
Keypad Overlay
Tools Required
Description
Part Number
Small straight blade screwdriver or Xacto knife
Isopropyl alcohol solution
1
unclip
Remove screw
